MSCM20XM10T3XG

In Stock: 6
MSCM20XM10T3XG - Microchip Technology - Transistors - FETs, MOSFETs - Arrays
REF: MSCM20XM10T3XG Microchip Technology
MSCM20XM10T3XG

Microchip Technology

PM-MOSFET-OTHER-SP3X

MSCM20XM10T3XG is a Transistors - FETs, MOSFETs - Arrays manufactured by Microchip Technology. PM-MOSFET-OTHER-SP3X. Key specifications: mounting type Chassis Mount, operating temperature -40°C ~ 125°C (Tc), package / case Module, power - max 341W (Tc).

Datasheet Request a Quote

In Stock: 6

Specifications

14 parameters
Product StatusActive
FET Type6 N-Channel (3-Phase Bridge)
FET FeatureStandard
Drain to Source Voltage (Vdss)200V
Current - Continuous Drain (Id) @ 25°C108A (Tc)
Rds On (Max) @ Id, Vgs9.7mOhm @ 81A, 10V
Vgs(th) (Max) @ Id5V @ 250µA
Gate Charge (Qg) (Max) @ Vgs161nC @ 10V
Input Capacitance (Ciss) (Max) @ Vds10.7nF @ 50V
Power - Max341W (Tc)
Operating Temperature-40°C ~ 125°C (Tc)
Mounting TypeChassis Mount
Package / CaseModule
Supplier Device PackageSP3X
