Name: TSM8568CS RLG
Brand: Taiwan Semiconductor Corporation
SKU: TSM8568CS RLG
Price: 2.59 USD
Availability: InStock

REF: TSM8568CS RLG Taiwan Semiconductor Corporation

TSM8568CS RLG

Taiwan Semiconductor Corporation

MOSFET N/P-CH 30V 15A/13A 8SOP

TSM8568CS RLG is a Transistors - FETs, MOSFETs - Arrays manufactured by Taiwan Semiconductor Corporation. MOSFET N/P-CH 30V 15A/13A 8SOP. Key specifications: mounting type Surface Mount, operating temperature -55°C ~ 150°C (TJ), package / case 8-SOIC (0.154", 3.90mm Width), power - max 6W.

Datasheet Request a Quote

In Stock: 30,740

Specifications

14 parameters

Product Status	Active
FET Type	N and P-Channel
FET Feature	Standard
Drain to Source Voltage (Vdss)	30V
Current - Continuous Drain (Id) @ 25°C	15A (Tc), 13A (Tc)
Rds On (Max) @ Id, Vgs	16mOhm @ 8A, 10V, 24mOhm @ 7A, 10V
Vgs(th) (Max) @ Id	2.5V @ 250µA

Gate Charge (Qg) (Max) @ Vgs	7nC @ 4.5V, 11nC @ 4.5V
Input Capacitance (Ciss) (Max) @ Vds	646pF @ 15V, 1089pF @ 15V
Power - Max	6W
Operating Temperature	-55°C ~ 150°C (TJ)
Mounting Type	Surface Mount
Package / Case	8-SOIC (0.154", 3.90mm Width)
Supplier Device Package	8-SOP
