Name: HCT802TXV
Brand: TT Electronics/Optek Technology
SKU: HCT802TXV
Availability: InStock

REF: HCT802TXV TT Electronics/Optek Technology

HCT802TXV

MOSFET N/P-CH 90V 2A/1.1A SMD

HCT802TXV is a Transistors - FETs, MOSFETs - Arrays manufactured by TT Electronics/Optek Technology. MOSFET N/P-CH 90V 2A/1.1A SMD. Key specifications: mounting type Surface Mount, operating temperature -55°C ~ 150°C (TJ), package / case 6-SMD, No Lead, power - max 500mW.

Datasheet Request a Quote

In Stock: 3,118

Specifications

14 parameters

Product Status	Obsolete
FET Type	N and P-Channel
FET Feature	Standard
Drain to Source Voltage (Vdss)	90V
Current - Continuous Drain (Id) @ 25°C	2A, 1.1A
Rds On (Max) @ Id, Vgs	5Ohm @ 1A, 10V
Vgs(th) (Max) @ Id	2.5V @ 1mA

Gate Charge (Qg) (Max) @ Vgs	-
Input Capacitance (Ciss) (Max) @ Vds	70pF @ 25V
Power - Max	500mW
Operating Temperature	-55°C ~ 150°C (TJ)
Mounting Type	Surface Mount
Package / Case	6-SMD, No Lead
Supplier Device Package	6-SMD
