Name: ADG5401FBCPZ-RL7
Brand: Analog Devices Inc.
SKU: ADG5401FBCPZ-RL7
Price: 8.39 USD
Availability: InStock

REF: ADG5401FBCPZ-RL7 Analog Devices Inc.

ADG5401FBCPZ-RL7

Analog Devices Inc.

60V OV PROTECTED HV SPSTX1 SWITC

ADG5401FBCPZ-RL7 is a Interface - Analog Switches, Multiplexers, Demultiplexers manufactured by Analog Devices Inc.. 60V OV PROTECTED HV SPSTX1 SWITC. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 125°C, package / case 10-WFDFN, CSP, number of circuits 1.

Datasheet Request a Quote

In Stock: 1,367

Tiered Pricing USD

1+ $8.3900 —

10+ $5.6330 -33%

25+ $4.9144 -41%

100+ $4.1026 -51%

250+ $3.7040 -56%

500+ $3.6125 -57% BEST

Specifications

18 parameters

Product Status	Active
Switch Circuit	SPST - NC
Multiplexer/Demultiplexer Circuit	1:1
Number of Circuits	1
On-State Resistance (Max)	6Ohm (Typ)
Channel-to-Channel Matching (ΔRon)	-
Voltage - Supply, Single (V+)	8V ~ 44V, ±5V ~ 22V
Voltage - Supply, Dual (V±)	8V ~ 44V, ±5V ~ 22V
Switch Time (Ton, Toff) (Max)	10.2µs, 360ns

-3db Bandwidth	395MHz
Charge Injection	-230pC
Channel Capacitance (CS(off), CD(off))	9pF, 11pF
Current - Leakage (IS(off)) (Max)	100pA (Typ)
Crosstalk	-
Operating Temperature	-40°C ~ 125°C
Mounting Type	Surface Mount
Package / Case	10-WFDFN, CSP
Supplier Device Package	10-LFCSP (3x2)
