Name: ADG528ATQ
Brand: Analog Devices Inc.
SKU: ADG528ATQ
Price: 45.37 USD
Availability: InStock

REF: ADG528ATQ Analog Devices Inc.

ADG528ATQ

IC MULTIPLEXER 8X1 18CDIP

ADG528ATQ is a Interface - Analog Switches, Multiplexers, Demultiplexers manufactured by Analog Devices Inc.. IC MULTIPLEXER 8X1 18CDIP. Key specifications: mounting type Through Hole, operating temperature -55°C ~ 125°C (TA), package / case 18-CDIP (0.300", 7.62mm), number of circuits 1.

Datasheet Request a Quote

In Stock: 171

Tiered Pricing USD

1+ $45.3700 —

21+ $32.5876 -28% BEST

Specifications

18 parameters

Product Status	Active
Switch Circuit	-
Multiplexer/Demultiplexer Circuit	8:1
Number of Circuits	1
On-State Resistance (Max)	450Ohm
Channel-to-Channel Matching (ΔRon)	22.5Ohm
Voltage - Supply, Single (V+)	10.8V ~ 16.5V
Voltage - Supply, Dual (V±)	±10.8V ~ 16.5V
Switch Time (Ton, Toff) (Max)	300ns, 300ns

-3db Bandwidth	-
Charge Injection	4pC
Channel Capacitance (CS(off), CD(off))	5pF, 22pF
Current - Leakage (IS(off)) (Max)	1nA
Crosstalk	-
Operating Temperature	-55°C ~ 125°C (TA)
Mounting Type	Through Hole
Package / Case	18-CDIP (0.300", 7.62mm)
Supplier Device Package	18-CERDIP
