Name: VS-P105W
Brand: Vishay General Semiconductor - Diodes Division
SKU: VS-P105W
Price: 40.45 USD
Availability: InStock

REF: VS-P105W Vishay General Semiconductor - Diodes Division

VS-P105W

Vishay General Semiconductor - Diodes Division

SCR HY-BRIDGE 1200V 25A PACE-PAK

VS-P105W is a Thyristors - SCRs - Modules manufactured by Vishay General Semiconductor - Diodes Division. SCR HY-BRIDGE 1200V 25A PACE-PAK. Key specifications: mounting type Chassis Mount, operating temperature -40°C ~ 125°C (TJ), package / case 8-PACE-PAK.

Datasheet Request a Quote

In Stock: 9,214

Tiered Pricing USD

1+ $40.4500 —

10+ $30.2050 -25%

100+ $27.4425 -32% BEST

Specifications

13 parameters

Product Status	Active
Structure	Bridge, Single Phase - SCRs/Diodes (Layout 1)
Number of SCRs, Diodes	2 SCRs, 2 Diodes
Voltage - Off State	1.2 kV
Current - On State (It (AV)) (Max)	-
Current - On State (It (RMS)) (Max)	-
Voltage - Gate Trigger (Vgt) (Max)	2 V

Current - Gate Trigger (Igt) (Max)	60 mA
Current - Non Rep. Surge 50, 60Hz (Itsm)	357A, 375A
Current - Hold (Ih) (Max)	130 mA
Operating Temperature	-40°C ~ 125°C (TJ)
Mounting Type	Chassis Mount
Package / Case	8-PACE-PAK
