Name: VS-P103
Brand: Vishay General Semiconductor - Diodes Division
SKU: VS-P103
Price: 28.27 USD
Availability: InStock

REF: VS-P103 Vishay General Semiconductor - Diodes Division

VS-P103

Vishay General Semiconductor - Diodes Division

MOD BRIDGE CC 25A 800V D-19

VS-P103 is a Thyristors - SCRs - Modules manufactured by Vishay General Semiconductor - Diodes Division. MOD BRIDGE CC 25A 800V D-19. Key specifications: mounting type Chassis Mount, operating temperature -40°C ~ 125°C (TJ), package / case 8-PACE-PAK.

Datasheet Request a Quote

In Stock: 1,570

Specifications

13 parameters

Product Status	Active
Structure	Bridge, Single Phase - SCRs/Diodes (Layout 1)
Number of SCRs, Diodes	2 SCRs, 2 Diodes
Voltage - Off State	800 V
Current - On State (It (AV)) (Max)	-
Current - On State (It (RMS)) (Max)	-
Voltage - Gate Trigger (Vgt) (Max)	2 V

Current - Gate Trigger (Igt) (Max)	60 mA
Current - Non Rep. Surge 50, 60Hz (Itsm)	357A, 375A
Current - Hold (Ih) (Max)	130 mA
Operating Temperature	-40°C ~ 125°C (TJ)
Mounting Type	Chassis Mount
Package / Case	8-PACE-PAK
