PD25FG80

In Stock: 3,036
PD25FG80 - SanRex Corporation - Thyristors - SCRs - Modules
REF: PD25FG80 SanRex Corporation
PD25FG80

SanRex Corporation

THYRISTOR MODULE 1600V 25A

PD25FG80 is a Thyristors - SCRs - Modules manufactured by SanRex Corporation. THYRISTOR MODULE 1600V 25A. Key specifications: mounting type Chassis Mount, operating temperature -40°C ~ 125°C (TJ), package / case Module.

Datasheet Request a Quote

In Stock: 3,036

Tiered Pricing USD
1+ $38.0100 —
10+ $28.2780 -26%
100+ $25.4000 -33% BEST

Specifications

13 parameters
Product StatusActive
StructureSeries Connection - SCR/Diode
Number of SCRs, Diodes1 SCR, 1 Diode
Voltage - Off State800 V
Current - On State (It (AV)) (Max)25 A
Current - On State (It (RMS)) (Max)39 A
Voltage - Gate Trigger (Vgt) (Max)3 V
Current - Gate Trigger (Igt) (Max)50 mA
Current - Non Rep. Surge 50, 60Hz (Itsm)640A, 700A
Current - Hold (Ih) (Max)-
Operating Temperature-40°C ~ 125°C (TJ)
Mounting TypeChassis Mount
Package / CaseModule
