Name: VHF28-08IO5
Brand: IXYS
SKU: VHF28-08IO5
Price: 17.45 USD
Availability: InStock

REF: VHF28-08IO5 IXYS

VHF28-08IO5

RECT BRIDGE 1PH 800V FO-F-A

VHF28-08IO5 is a Thyristors - SCRs - Modules manufactured by IXYS. RECT BRIDGE 1PH 800V FO-F-A. Key specifications: mounting type Chassis Mount, operating temperature -40°C ~ 125°C (TJ), package / case FO-F-A.

Datasheet Request a Quote

In Stock: 8,757

Specifications

13 parameters

Product Status	Active
Structure	Bridge, Single Phase - SCRs/Diodes (Layout 1)
Number of SCRs, Diodes	2 SCRs, 2 Diodes
Voltage - Off State	800 V
Current - On State (It (AV)) (Max)	28 A
Current - On State (It (RMS)) (Max)	-
Voltage - Gate Trigger (Vgt) (Max)	1 V

Current - Gate Trigger (Igt) (Max)	65 mA
Current - Non Rep. Surge 50, 60Hz (Itsm)	300A, 330A
Current - Hold (Ih) (Max)	100 mA
Operating Temperature	-40°C ~ 125°C (TJ)
Mounting Type	Chassis Mount
Package / Case	FO-F-A
