MCNA120UI2200TED

In Stock: 3,245
MCNA120UI2200TED - IXYS - Thyristors - SCRs - Modules
REF: MCNA120UI2200TED IXYS
MCNA120UI2200TED

IXYS

MOD THYRISTOR TRI 22KV E2

MCNA120UI2200TED is a Thyristors - SCRs - Modules manufactured by IXYS. MOD THYRISTOR TRI 22KV E2. Key specifications: mounting type Chassis Mount, operating temperature -40°C ~ 150°C (TJ), package / case E2.

Datasheet Request a Quote

In Stock: 3,245

Specifications

13 parameters
Product StatusActive
StructureBridge, 3-Phase - SCRs/Diodes - IGBT with Diode
Number of SCRs, Diodes3 SCRs, 3 Diodes
Voltage - Off State2.2 kV
Current - On State (It (AV)) (Max)-
Current - On State (It (RMS)) (Max)-
Voltage - Gate Trigger (Vgt) (Max)1.4 V
Current - Gate Trigger (Igt) (Max)70 mA
Current - Non Rep. Surge 50, 60Hz (Itsm)500A, 540A
Current - Hold (Ih) (Max)100 mA
Operating Temperature-40°C ~ 150°C (TJ)
Mounting TypeChassis Mount
Package / CaseE2
