Name: HCT7000MTXV
Brand: TT Electronics/Optek Technology
SKU: HCT7000MTXV
Availability: InStock

REF: HCT7000MTXV TT Electronics/Optek Technology

HCT7000MTXV

MOSFET N-CH 60V 200MA 3SMD

HCT7000MTXV is a Transistors - FETs, MOSFETs - Single manufactured by TT Electronics/Optek Technology. MOSFET N-CH 60V 200MA 3SMD. Key specifications: mounting type Surface Mount, operating temperature -55°C ~ 150°C (TJ), package / case 3-SMD, No Lead.

Datasheet Request a Quote

In Stock: 1,658

Specifications

17 parameters

Product Status	Obsolete
FET Type	N-Channel
Technology	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)	60 V
Current - Continuous Drain (Id) @ 25°C	200mA (Ta)
Drive Voltage (Max Rds On, Min Rds On)	10V
Rds On (Max) @ Id, Vgs	5Ohm @ 500mA, 10V
Vgs(th) (Max) @ Id	3V @ 1mA
Gate Charge (Qg) (Max) @ Vgs	-

Vgs (Max)	±40V
Input Capacitance (Ciss) (Max) @ Vds	60 pF @ 25 V
FET Feature	-
Power Dissipation (Max)	300mW (Ta)
Operating Temperature	-55°C ~ 150°C (TJ)
Mounting Type	Surface Mount
Supplier Device Package	3-SMD
Package / Case	3-SMD, No Lead
