TPCA8010-H(TE12L,Q

In Stock: 3,142
TPCA8010-H(TE12L,Q - Toshiba Semiconductor and Storage - Transistors - FETs, MOSFETs - Single
REF: TPCA8010-H(TE12L,Q Toshiba Semiconductor and Storage
TPCA8010-H(TE12L,Q

Toshiba Semiconductor and Storage

MOSFET N-CH 200V 5.5A 8SOP

TPCA8010-H(TE12L,Q is a Transistors - FETs, MOSFETs - Single manufactured by Toshiba Semiconductor and Storage. MOSFET N-CH 200V 5.5A 8SOP. Key specifications: mounting type Surface Mount, operating temperature 150°C (TJ), package / case 8-PowerVDFN.

Datasheet Request a Quote

In Stock: 3,142

Specifications

17 parameters
Product StatusObsolete
FET TypeN-Channel
TechnologyMOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)200 V
Current - Continuous Drain (Id) @ 25°C5.5A (Ta)
Drive Voltage (Max Rds On, Min Rds On)10V
Rds On (Max) @ Id, Vgs450mOhm @ 2.7A, 10V
Vgs(th) (Max) @ Id4V @ 1mA
Gate Charge (Qg) (Max) @ Vgs10 nC @ 10 V
Vgs (Max)±20V
Input Capacitance (Ciss) (Max) @ Vds600 pF @ 10 V
FET Feature-
Power Dissipation (Max)1.6W (Ta), 45W (Tc)
Operating Temperature150°C (TJ)
Mounting TypeSurface Mount
Supplier Device Package8-SOP Advance (5x5)
Package / Case8-PowerVDFN
