TLP2770(D4-TP,E

In Stock: 5,838
TLP2770(D4-TP,E - Toshiba Semiconductor and Storage - Optoisolators - Logic Output
REF: TLP2770(D4-TP,E Toshiba Semiconductor and Storage
TLP2770(D4-TP,E

Toshiba Semiconductor and Storage

OPTOISO 5KV TRI-STATE S06L

TLP2770(D4-TP,E is a Optoisolators - Logic Output manufactured by Toshiba Semiconductor and Storage. OPTOISO 5KV TRI-STATE S06L. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 125°C, voltage - supply 2.7V ~ 5.5V, package / case 6-SOIC (0.295", 7.50mm Width).

Datasheet Request a Quote

In Stock: 5,838

Tiered Pricing USD
1+ $2.2100 —
10+ $1.5900 -28%
100+ $1.2189 -45%
500+ $1.0552 -52% BEST

Specifications

18 parameters
Product StatusActive
Number of Channels1
Inputs - Side 1/Side 21/0
Voltage - Isolation5000Vrms
Common Mode Transient Immunity (Min)20kV/µs
Input TypeDC
Output TypePush-Pull, Totem Pole
Current - Output / Channel10 mA
Data Rate20MBd
Propagation Delay tpLH / tpHL (Max)60ns, 60ns
Rise / Fall Time (Typ)1.3ns, 1ns
Voltage - Forward (Vf) (Typ)1.5V
Current - DC Forward (If) (Max)8mA
Voltage - Supply2.7V ~ 5.5V
Operating Temperature-40°C ~ 125°C
Mounting TypeSurface Mount
Package / Case6-SOIC (0.295", 7.50mm Width)
Supplier Device Package6-SO
