Name: 2SK3309(Q)
Brand: Toshiba Semiconductor and Storage
SKU: 2SK3309(Q)
Availability: InStock

REF: 2SK3309(Q) Toshiba Semiconductor and Storage

2SK3309(Q)

MOSFET N-CH 450V 10A TO220FL

2SK3309(Q) is a Transistors - FETs, MOSFETs - Single manufactured by Toshiba Semiconductor and Storage. MOSFET N-CH 450V 10A TO220FL. Key specifications: mounting type Through Hole, operating temperature 150°C (TJ), package / case TO-220-3, Short Tab.

Datasheet Request a Quote

In Stock: 7,929

Specifications

17 parameters

Product Status	Obsolete
FET Type	N-Channel
Technology	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)	450 V
Current - Continuous Drain (Id) @ 25°C	10A (Ta)
Drive Voltage (Max Rds On, Min Rds On)	10V
Rds On (Max) @ Id, Vgs	650mOhm @ 5A, 10V
Vgs(th) (Max) @ Id	5V @ 1mA
Gate Charge (Qg) (Max) @ Vgs	23 nC @ 10 V

Vgs (Max)	±30V
Input Capacitance (Ciss) (Max) @ Vds	920 pF @ 10 V
FET Feature	-
Power Dissipation (Max)	65W (Tc)
Operating Temperature	150°C (TJ)
Mounting Type	Through Hole
Supplier Device Package	TO-220FL
Package / Case	TO-220-3, Short Tab
