Name: 2SK2376(Q)
Brand: Toshiba Semiconductor and Storage
SKU: 2SK2376(Q)
Availability: InStock

REF: 2SK2376(Q) Toshiba Semiconductor and Storage

2SK2376(Q)

MOSFET N-CH 60V 45A TO220FL

2SK2376(Q) is a Transistors - FETs, MOSFETs - Single manufactured by Toshiba Semiconductor and Storage. MOSFET N-CH 60V 45A TO220FL. Key specifications: mounting type Through Hole, operating temperature 150°C (TJ), package / case TO-220-3, Short Tab.

Datasheet Request a Quote

In Stock: 2,834

Specifications

17 parameters

Product Status	Obsolete
FET Type	N-Channel
Technology	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)	60 V
Current - Continuous Drain (Id) @ 25°C	45A (Ta)
Drive Voltage (Max Rds On, Min Rds On)	4V, 10V
Rds On (Max) @ Id, Vgs	17mOhm @ 25A, 10V
Vgs(th) (Max) @ Id	2V @ 1mA
Gate Charge (Qg) (Max) @ Vgs	110 nC @ 10 V

Vgs (Max)	±20V
Input Capacitance (Ciss) (Max) @ Vds	3350 pF @ 10 V
FET Feature	-
Power Dissipation (Max)	100W (Tc)
Operating Temperature	150°C (TJ)
Mounting Type	Through Hole
Supplier Device Package	TO-220FL
Package / Case	TO-220-3, Short Tab
