SN74S86N

In Stock: 28,776
SN74S86N - Texas Instruments - Logic - Gates and Inverters
REF: SN74S86N Texas Instruments
SN74S86N

Texas Instruments

IC GATE XOR 4CH 2-INP 14-DIP

SN74S86N is a Logic - Gates and Inverters manufactured by Texas Instruments. IC GATE XOR 4CH 2-INP 14-DIP. Key specifications: mounting type Through Hole, operating temperature 0°C ~ 70°C, voltage - supply 4.75V ~ 5.25V, package / case 14-DIP (0.300", 7.62mm).

Datasheet Request a Quote

In Stock: 28,776

Specifications

15 parameters
Product StatusObsolete
Logic TypeXOR (Exclusive OR)
Number of Circuits4
Number of Inputs2
Features-
Voltage - Supply4.75V ~ 5.25V
Current - Quiescent (Max)-
Current - Output High, Low1mA, 20mA
Logic Level - Low0.8V
Logic Level - High2V
Max Propagation Delay @ V, Max CL10.5ns @ 5V, 15pF
Operating Temperature0°C ~ 70°C
Mounting TypeThrough Hole
Supplier Device Package14-PDIP
Package / Case14-DIP (0.300", 7.62mm)
