Name: SN74LVC1G14DPWR
Brand: Texas Instruments
SKU: SN74LVC1G14DPWR
Price: 0.26 USD
Availability: InStock

REF: SN74LVC1G14DPWR Texas Instruments

SN74LVC1G14DPWR

Texas Instruments

IC INVERT SCHMITT 1CH 1IN 5X2SON

SN74LVC1G14DPWR is a Logic - Gates and Inverters manufactured by Texas Instruments. IC INVERT SCHMITT 1CH 1IN 5X2SON. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 85°C, voltage - supply 1.65V ~ 5.5V, package / case 5-XFDFN Exposed Pad.

Datasheet Request a Quote

In Stock: 2,013

Tiered Pricing USD

1+ $0.2600 —

10+ $0.1760 -32%

25+ $0.1560 -40%

100+ $0.1336 -49%

250+ $0.1229 -53%

500+ $0.1165 -55%

1,000+ $0.1112 -57% BEST

Specifications

15 parameters

Product Status	Active
Logic Type	Inverter
Number of Circuits	1
Number of Inputs	1
Features	Schmitt Trigger
Voltage - Supply	1.65V ~ 5.5V
Current - Quiescent (Max)	10 µA
Current - Output High, Low	32mA, 32mA

Logic Level - Low	0.39V ~ 1.87V
Logic Level - High	1.16V ~ 3.33V
Max Propagation Delay @ V, Max CL	5ns @ 5V, 50pF
Operating Temperature	-40°C ~ 85°C
Mounting Type	Surface Mount
Supplier Device Package	5-X2SON (0.8x0.8)
Package / Case	5-XFDFN Exposed Pad
