Name: SN74LVC1G00DPWR
Brand: Texas Instruments
SKU: SN74LVC1G00DPWR
Price: 0.25 USD
Availability: InStock

REF: SN74LVC1G00DPWR Texas Instruments

SN74LVC1G00DPWR

Texas Instruments

IC GATE NAND 1CH 2-INP 4X2SON

SN74LVC1G00DPWR is a Logic - Gates and Inverters manufactured by Texas Instruments. IC GATE NAND 1CH 2-INP 4X2SON. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 125°C, voltage - supply 1.65V ~ 5.5V, package / case 4-XFDFN Exposed Pad.

Datasheet Request a Quote

In Stock: 8,635

Tiered Pricing USD

1+ $0.2500 —

10+ $0.1740 -30%

25+ $0.1540 -38%

100+ $0.1318 -47%

250+ $0.1213 -51%

500+ $0.1149 -54%

1,000+ $0.1097 -56% BEST

Specifications

15 parameters

Product Status	Active
Logic Type	NAND Gate
Number of Circuits	1
Number of Inputs	2
Features	-
Voltage - Supply	1.65V ~ 5.5V
Current - Quiescent (Max)	10 µA
Current - Output High, Low	32mA, 32mA

Logic Level - Low	0.7V ~ 0.8V
Logic Level - High	1.7V ~ 2V
Max Propagation Delay @ V, Max CL	4.3ns @ 5V, 50pF
Operating Temperature	-40°C ~ 125°C
Mounting Type	Surface Mount
Supplier Device Package	4-X2SON (0.8x0.8)
Package / Case	4-XFDFN Exposed Pad
