Name: SN74LV4052ADGVR
Brand: Texas Instruments
SKU: SN74LV4052ADGVR
Price: 0.63 USD
Availability: InStock

REF: SN74LV4052ADGVR Texas Instruments

SN74LV4052ADGVR

Texas Instruments

IC MULTIPLEXER DUAL 4X1 16TVSOP

SN74LV4052ADGVR is a Interface - Analog Switches, Multiplexers, Demultiplexers manufactured by Texas Instruments. IC MULTIPLEXER DUAL 4X1 16TVSOP. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 85°C (TA), package / case 16-TFSOP (0.173", 4.40mm Width), number of circuits 2.

Datasheet Request a Quote

In Stock: 7,800

Tiered Pricing USD

1+ $0.6300 —

10+ $0.4450 -29%

25+ $0.3988 -37%

100+ $0.3480 -45%

250+ $0.3238 -49%

500+ $0.3093 -51%

1,000+ $0.3029 -52% BEST

Specifications

18 parameters

Product Status	Active
Switch Circuit	SP4T
Multiplexer/Demultiplexer Circuit	4:1
Number of Circuits	2
On-State Resistance (Max)	75Ohm
Channel-to-Channel Matching (ΔRon)	700mOhm
Voltage - Supply, Single (V+)	2V ~ 5.5V
Voltage - Supply, Dual (V±)	-
Switch Time (Ton, Toff) (Max)	14ns, 14ns

-3db Bandwidth	50MHz
Charge Injection	-
Channel Capacitance (CS(off), CD(off))	0.5pF, 13.1pF
Current - Leakage (IS(off)) (Max)	100nA
Crosstalk	-45dB @ 1MHz
Operating Temperature	-40°C ~ 85°C (TA)
Mounting Type	Surface Mount
Package / Case	16-TFSOP (0.173", 4.40mm Width)
Supplier Device Package	16-TVSOP
