Name: VN02AN-11-E
Brand: STMicroelectronics
SKU: VN02AN-11-E
Price: 1.67 USD
Availability: InStock

REF: VN02AN-11-E STMicroelectronics

VN02AN-11-E

IC PWR DRVR N-CH 1:1 5PENTAWATT

VN02AN-11-E is a PMIC - Power Distribution Switches, Load Drivers manufactured by STMicroelectronics. IC PWR DRVR N-CH 1:1 5PENTAWATT. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 150°C (TJ), voltage - supply (vcc/vdd) Not Required, package / case Pentawatt-5 (Vertical, Bent and Staggered Leads).

Datasheet Request a Quote

In Stock: 1,248

Specifications

18 parameters

Product Status	Obsolete
Switch Type	General Purpose
Number of Outputs	1
Ratio - Input:Output	1:1
Output Configuration	High Side
Output Type	N-Channel
Interface	On/Off
Voltage - Load	7V ~ 36V
Voltage - Supply (Vcc/Vdd)	Not Required

Current - Output (Max)	7A
Rds On (Typ)	350mOhm (Max)
Input Type	Non-Inverting
Features	-
Fault Protection	Over Temperature
Operating Temperature	-40°C ~ 150°C (TJ)
Mounting Type	Through Hole
Supplier Device Package	5-PENTAWATT
Package / Case	Pentawatt-5 (Vertical, Bent and Staggered Leads)
