STP26N60M2

In Stock: 8,649
STP26N60M2 - STMicroelectronics - Transistors - FETs, MOSFETs - Single
REF: STP26N60M2 STMicroelectronics
STP26N60M2

STMicroelectronics

MOSFET N-CHANNEL 600V 20A TO220

STP26N60M2 is a Transistors - FETs, MOSFETs - Single manufactured by STMicroelectronics. MOSFET N-CHANNEL 600V 20A TO220. Key specifications: mounting type Through Hole, package / case TO-220-3.

Datasheet Request a Quote

In Stock: 8,649

Specifications

17 parameters
Product StatusActive
FET TypeN-Channel
TechnologyMOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)600 V
Current - Continuous Drain (Id) @ 25°C20A (Tc)
Drive Voltage (Max Rds On, Min Rds On)10V
Rds On (Max) @ Id, Vgs-
Vgs(th) (Max) @ Id-
Gate Charge (Qg) (Max) @ Vgs-
Vgs (Max)-
Input Capacitance (Ciss) (Max) @ Vds-
FET Feature-
Power Dissipation (Max)169W (Tc)
Operating Temperature-
Mounting TypeThrough Hole
Supplier Device PackageTO-220
Package / CaseTO-220-3
