PC410L0YIP

In Stock: 6,399
PC410L0YIP - Sharp Microelectronics - Optoisolators - Logic Output
REF: PC410L0YIP Sharp Microelectronics
PC410L0YIP

Sharp Microelectronics

OPTOISO 3.75KV OPEN COLL 5MFP

PC410L0YIP is a Optoisolators - Logic Output manufactured by Sharp Microelectronics. OPTOISO 3.75KV OPEN COLL 5MFP. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 85°C, voltage - supply 4.5V ~ 5.5V, package / case 6-SOIC (0.173", 4.40mm Width), 5 Leads.

Datasheet Request a Quote

In Stock: 6,399

Tiered Pricing USD
3,000+ $1.1875 —
6,000+ $1.1488 -3% BEST

Specifications

18 parameters
Product StatusObsolete
Number of Channels1
Inputs - Side 1/Side 21/0
Voltage - Isolation3750Vrms
Common Mode Transient Immunity (Min)10kV/µs
Input TypeDC
Output TypeOpen Collector
Current - Output / Channel50 mA
Data Rate10Mbps
Propagation Delay tpLH / tpHL (Max)75ns, 75ns
Rise / Fall Time (Typ)10ns, 20ns
Voltage - Forward (Vf) (Typ)1.6V
Current - DC Forward (If) (Max)20mA
Voltage - Supply4.5V ~ 5.5V
Operating Temperature-40°C ~ 85°C
Mounting TypeSurface Mount
Package / Case6-SOIC (0.173", 4.40mm Width), 5 Leads
Supplier Device Package5-MFP
