PS9309L2-V-E3-AX

In Stock: 7,849
PS9309L2-V-E3-AX - Renesas Electronics America Inc - Optoisolators - Logic Output
REF: PS9309L2-V-E3-AX Renesas Electronics America Inc
PS9309L2-V-E3-AX

Renesas Electronics America Inc

OPTOISO 5KV PUSH PULL 6SDIP

PS9309L2-V-E3-AX is a Optoisolators - Logic Output manufactured by Renesas Electronics America Inc. OPTOISO 5KV PUSH PULL 6SDIP. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 110°C, voltage - supply 4.5V ~ 20V, package / case 6-SOIC (0.268", 6.80mm Width).

Datasheet Request a Quote

In Stock: 7,849

Tiered Pricing USD
1+ $4.9700 —
10+ $3.6980 -26%
100+ $2.9468 -41%
500+ $2.6184 -47%
1,000+ $2.6163 -47% BEST

Specifications

18 parameters
Product StatusActive
Number of Channels1
Inputs - Side 1/Side 21/0
Voltage - Isolation5000Vrms
Common Mode Transient Immunity (Min)15kV/µs
Input TypeDC
Output TypePush-Pull, Totem Pole
Current - Output / Channel25 mA
Data Rate1Mbps
Propagation Delay tpLH / tpHL (Max)200ns, 200ns
Rise / Fall Time (Typ)24ns, 3.2ns
Voltage - Forward (Vf) (Typ)1.55V
Current - DC Forward (If) (Max)20mA
Voltage - Supply4.5V ~ 20V
Operating Temperature-40°C ~ 110°C
Mounting TypeSurface Mount
Package / Case6-SOIC (0.268", 6.80mm Width)
Supplier Device Package6-SDIP Gull Wing
