Name: PS9009-Y-AX
Brand: Renesas Electronics America Inc
SKU: PS9009-Y-AX
Price: 5.61 USD
Availability: InStock

REF: PS9009-Y-AX Renesas Electronics America Inc

PS9009-Y-AX

Renesas Electronics America Inc

LSO-5

PS9009-Y-AX is a Optoisolators - Logic Output manufactured by Renesas Electronics America Inc. LSO-5. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 125°C, voltage - supply 4.5V ~ 20V, package / case 6-SOIC (0.295", 7.50mm Width), 5 Leads.

Datasheet Request a Quote

In Stock: 1,780

Tiered Pricing USD

1+ $5.6100 —

20+ $3.8930 -31%

100+ $3.3599 -40%

500+ $2.9963 -47%

1,000+ $2.8782 -49%

2,000+ $2.7783 -50% BEST

Specifications

18 parameters

Product Status	Active
Number of Channels	1
Inputs - Side 1/Side 2	1/0
Voltage - Isolation	5000Vrms
Common Mode Transient Immunity (Min)	50kV/µs
Input Type	DC
Output Type	Push-Pull, Totem Pole
Current - Output / Channel	25 mA
Data Rate	-

Propagation Delay tpLH / tpHL (Max)	200ns, 200ns
Rise / Fall Time (Typ)	25ns, 4.6ns
Voltage - Forward (Vf) (Typ)	1.56V
Current - DC Forward (If) (Max)	25mA
Voltage - Supply	4.5V ~ 20V
Operating Temperature	-40°C ~ 125°C
Mounting Type	Surface Mount
Package / Case	6-SOIC (0.295", 7.50mm Width), 5 Leads
Supplier Device Package	5-LSOP
