Name: PS9001-Y-F3-AX
Brand: Renesas Electronics America Inc
SKU: PS9001-Y-F3-AX
Price: 2.01 USD
Availability: InStock

REF: PS9001-Y-F3-AX Renesas Electronics America Inc

PS9001-Y-F3-AX

Renesas Electronics America Inc

HI-SPEED OPTOCPLR LSO5

PS9001-Y-F3-AX is a Optoisolators - Logic Output manufactured by Renesas Electronics America Inc. HI-SPEED OPTOCPLR LSO5. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 125°C, voltage - supply 4.5V ~ 5.5V, package / case 6-SOIC (0.295", 7.50mm Width), 5 Leads.

Datasheet Request a Quote

In Stock: 8,244

Tiered Pricing USD

1+ $2.0100 —

10+ $1.4440 -28%

100+ $1.1016 -45%

500+ $0.9507 -53%

1,000+ $0.9015 -55% BEST

Specifications

18 parameters

Product Status	Active
Number of Channels	1
Inputs - Side 1/Side 2	1/0
Voltage - Isolation	5000Vrms
Common Mode Transient Immunity (Min)	50kV/µs
Input Type	DC
Output Type	Open Collector
Current - Output / Channel	20 mA
Data Rate	-

Propagation Delay tpLH / tpHL (Max)	100ns, 100ns
Rise / Fall Time (Typ)	-
Voltage - Forward (Vf) (Typ)	1.56V
Current - DC Forward (If) (Max)	25mA
Voltage - Supply	4.5V ~ 5.5V
Operating Temperature	-40°C ~ 125°C
Mounting Type	Surface Mount
Package / Case	6-SOIC (0.295", 7.50mm Width), 5 Leads
Supplier Device Package	5-LSOP
