NCP1377BP

In Stock: 4,600
NCP1377BP - onsemi - PMIC - AC DC Converters, Offline Switchers
REF: NCP1377BP onsemi
NCP1377BP

onsemi

IC OFFLINE SWITCH FLYBACK 7DIP

NCP1377BP is a PMIC - AC DC Converters, Offline Switchers manufactured by onsemi. IC OFFLINE SWITCH FLYBACK 7DIP. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 125°C (TJ), voltage - supply (vcc/vdd) 7.5V ~ 18V, package / case 8-DIP (0.300", 7.62mm), 7 Leads.

Datasheet Request a Quote

In Stock: 4,600

Specifications

16 parameters
Product StatusObsolete
Output IsolationIsolated
Internal Switch(s)No
Voltage - Breakdown-
TopologyFlyback
Voltage - Start Up12.5 V
Voltage - Supply (Vcc/Vdd)7.5V ~ 18V
Duty Cycle-
Frequency - SwitchingUp to 300kHz
Power (Watts)-
Fault ProtectionCurrent Limiting, Over Temperature, Over Voltage
Control Features-
Operating Temperature-40°C ~ 125°C (TJ)
Package / Case8-DIP (0.300", 7.62mm), 7 Leads
Supplier Device Package7-PDIP
Mounting TypeThrough Hole
