PMZB290UNE2YL

In Stock: 3,559
PMZB290UNE2YL - Nexperia USA Inc. - Transistors - FETs, MOSFETs - Single
REF: PMZB290UNE2YL Nexperia USA Inc.
PMZB290UNE2YL

Nexperia USA Inc.

MOSFET N-CH 20V 1.2A DFN1006B-3

PMZB290UNE2YL is a Transistors - FETs, MOSFETs - Single manufactured by Nexperia USA Inc.. MOSFET N-CH 20V 1.2A DFN1006B-3. Key specifications: mounting type Surface Mount, operating temperature -55°C ~ 150°C (TJ), package / case 3-XFDFN.

Datasheet Request a Quote

In Stock: 3,559

Specifications

17 parameters
Product StatusActive
FET TypeN-Channel
TechnologyMOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)20 V
Current - Continuous Drain (Id) @ 25°C1.2A (Ta)
Drive Voltage (Max Rds On, Min Rds On)1.5V, 4.5V
Rds On (Max) @ Id, Vgs320mOhm @ 1.2A, 4.5V
Vgs(th) (Max) @ Id950mV @ 250µA
Gate Charge (Qg) (Max) @ Vgs1.4 nC @ 4.5 V
Vgs (Max)±8V
Input Capacitance (Ciss) (Max) @ Vds46 pF @ 10 V
FET Feature-
Power Dissipation (Max)350mW (Ta), 5.43W (Tc)
Operating Temperature-55°C ~ 150°C (TJ)
Mounting TypeSurface Mount
Supplier Device PackageDFN1006B-3
Package / Case3-XFDFN
