Name: APT5SM170B
Brand: Microsemi Corporation
SKU: APT5SM170B
Availability: InStock

REF: APT5SM170B Microsemi Corporation

APT5SM170B

SICFET N-CH 1700V 5A TO247-3

APT5SM170B is a Transistors - FETs, MOSFETs - Single manufactured by Microsemi Corporation. SICFET N-CH 1700V 5A TO247-3. Key specifications: mounting type Through Hole, operating temperature -55°C ~ 175°C (TJ), package / case TO-247-3.

Datasheet Request a Quote

In Stock: 8,611

Specifications

17 parameters

Product Status	Obsolete
FET Type	N-Channel
Technology	SiCFET (Silicon Carbide)
Drain to Source Voltage (Vdss)	1700 V
Current - Continuous Drain (Id) @ 25°C	5A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	20V
Rds On (Max) @ Id, Vgs	1.25Ohm @ 2.5A, 20V
Vgs(th) (Max) @ Id	3.2V @ 500µA
Gate Charge (Qg) (Max) @ Vgs	21 nC @ 20 V

Vgs (Max)	+25V, -10V
Input Capacitance (Ciss) (Max) @ Vds	249 pF @ 1000 V
FET Feature	-
Power Dissipation (Max)	65W (Tc)
Operating Temperature	-55°C ~ 175°C (TJ)
Mounting Type	Through Hole
Supplier Device Package	TO-247-3
Package / Case	TO-247-3
