Name: LSIC1MO120G0160
Brand: Littelfuse Inc.
SKU: LSIC1MO120G0160
Availability: InStock

REF: LSIC1MO120G0160 Littelfuse Inc.

LSIC1MO120G0160

MOSFET SIC 1200V 14A TO247-4L

LSIC1MO120G0160 is a Transistors - FETs, MOSFETs - Single manufactured by Littelfuse Inc.. MOSFET SIC 1200V 14A TO247-4L. Key specifications: mounting type Through Hole, operating temperature -55°C ~ 175°C (TJ), package / case TO-247-4.

Datasheet Request a Quote

In Stock: 7,857

Specifications

17 parameters

Product Status	Active
FET Type	N-Channel
Technology	SiCFET (Silicon Carbide)
Drain to Source Voltage (Vdss)	1200 V
Current - Continuous Drain (Id) @ 25°C	22A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	20V
Rds On (Max) @ Id, Vgs	200mOhm @ 10A, 20V
Vgs(th) (Max) @ Id	4V @ 5mA
Gate Charge (Qg) (Max) @ Vgs	50 nC @ 20 V

Vgs (Max)	+22V, -6V
Input Capacitance (Ciss) (Max) @ Vds	890 pF @ 800 V
FET Feature	-
Power Dissipation (Max)	125W (Tc)
Operating Temperature	-55°C ~ 175°C (TJ)
Mounting Type	Through Hole
Supplier Device Package	TO-247-4L
Package / Case	TO-247-4
