LSIC1MO120G0040

In Stock: 2,480
LSIC1MO120G0040 - Littelfuse Inc. - Transistors - FETs, MOSFETs - Single
REF: LSIC1MO120G0040 Littelfuse Inc.
LSIC1MO120G0040

Littelfuse Inc.

MOSFET SIC 1200V 50A TO247-4L

LSIC1MO120G0040 is a Transistors - FETs, MOSFETs - Single manufactured by Littelfuse Inc.. MOSFET SIC 1200V 50A TO247-4L. Key specifications: mounting type Through Hole, operating temperature -55°C ~ 175°C (TJ), package / case TO-247-4.

Datasheet Request a Quote

In Stock: 2,480

Specifications

17 parameters
Product StatusActive
FET TypeN-Channel
TechnologySiCFET (Silicon Carbide)
Drain to Source Voltage (Vdss)1200 V
Current - Continuous Drain (Id) @ 25°C70A (Tc)
Drive Voltage (Max Rds On, Min Rds On)20V
Rds On (Max) @ Id, Vgs50mOhm @ 40A, 20V
Vgs(th) (Max) @ Id4V @ 20mA
Gate Charge (Qg) (Max) @ Vgs175 nC @ 20 V
Vgs (Max)+22V, -6V
Input Capacitance (Ciss) (Max) @ Vds317 pF @ 800 V
FET Feature-
Power Dissipation (Max)357W (Tc)
Operating Temperature-55°C ~ 175°C (TJ)
Mounting TypeThrough Hole
Supplier Device PackageTO-247-4L
Package / CaseTO-247-4
