LSIC1MO120G0025

In Stock: 4,108
LSIC1MO120G0025 - Littelfuse Inc. - Transistors - FETs, MOSFETs - Single
REF: LSIC1MO120G0025 Littelfuse Inc.
LSIC1MO120G0025

Littelfuse Inc.

MOSFET SIC 1200V 70A TO247-4L

LSIC1MO120G0025 is a Transistors - FETs, MOSFETs - Single manufactured by Littelfuse Inc.. MOSFET SIC 1200V 70A TO247-4L. Key specifications: mounting type Through Hole, operating temperature -55°C ~ 175°C (TJ), package / case TO-247-4.

Datasheet Request a Quote

In Stock: 4,108

Specifications

17 parameters
Product StatusActive
FET TypeN-Channel
TechnologySiCFET (Silicon Carbide)
Drain to Source Voltage (Vdss)1200 V
Current - Continuous Drain (Id) @ 25°C100A (Tc)
Drive Voltage (Max Rds On, Min Rds On)20V
Rds On (Max) @ Id, Vgs32mOhm @ 50A, 20V
Vgs(th) (Max) @ Id4V @ 30mA
Gate Charge (Qg) (Max) @ Vgs265 nC @ 20 V
Vgs (Max)+22V, -6V
Input Capacitance (Ciss) (Max) @ Vds495 pF @ 800 V
FET Feature-
Power Dissipation (Max)500W (Tc)
Operating Temperature-55°C ~ 175°C (TJ)
Mounting TypeThrough Hole
Supplier Device PackageTO-247-4L
Package / CaseTO-247-4
