Name: IXBH10N300HV
Brand: IXYS
SKU: IXBH10N300HV
Price: 63.48 USD
Availability: InStock

REF: IXBH10N300HV IXYS

IXBH10N300HV

IGBT 3000V 20A 140W TO247AD

IXBH10N300HV is a Transistors - IGBTs - Single manufactured by IXYS. IGBT 3000V 20A 140W TO247AD. Key specifications: mounting type Surface Mount, operating temperature -55°C ~ 150°C (TJ), package / case TO-263-3, D²Pak (2 Leads + Tab), TO-263AB, current - collector (ic) (max) 34 A.

Datasheet Request a Quote

In Stock: 7,125

Specifications

17 parameters

Product Status	Active
IGBT Type	-
Voltage - Collector Emitter Breakdown (Max)	3000 V
Current - Collector (Ic) (Max)	34 A
Current - Collector Pulsed (Icm)	88 A
Vce(on) (Max) @ Vge, Ic	2.8V @ 15V, 10A
Power - Max	180 W
Switching Energy	-
Input Type	Standard

Gate Charge	46 nC
Td (on/off) @ 25°C	36ns/100ns
Test Condition	960V, 10A, 10Ohm, 15V
Reverse Recovery Time (trr)	1.6 µs
Operating Temperature	-55°C ~ 150°C (TJ)
Mounting Type	Surface Mount
Package / Case	TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
Supplier Device Package	TO-263HV
