Name: DG528CY
Brand: Harris Corporation
SKU: DG528CY
Price: 2.61 USD
Availability: InStock

REF: DG528CY Harris Corporation

DG528CY

ANALOG LATCHABLE MUX, 8-CHANNEL

DG528CY is a Interface - Analog Switches, Multiplexers, Demultiplexers manufactured by Harris Corporation. ANALOG LATCHABLE MUX, 8-CHANNEL. Key specifications: mounting type Surface Mount, operating temperature 0°C ~ 70°C, package / case 18-SOIC (0.295", 7.50mm Width), number of circuits 1.

Datasheet Request a Quote

In Stock: 1,503

Specifications

18 parameters

Product Status	Active
Switch Circuit	-
Multiplexer/Demultiplexer Circuit	8:1
Number of Circuits	1
On-State Resistance (Max)	450Ohm
Channel-to-Channel Matching (ΔRon)	27Ohm
Voltage - Supply, Single (V+)	44V
Voltage - Supply, Dual (V±)	44V
Switch Time (Ton, Toff) (Max)	1µs (Typ), 400ns (Typ)

-3db Bandwidth	-
Charge Injection	4pC
Channel Capacitance (CS(off), CD(off))	5pF, 25pF
Current - Leakage (IS(off)) (Max)	5nA
Crosstalk	-
Operating Temperature	0°C ~ 70°C
Mounting Type	Surface Mount
Package / Case	18-SOIC (0.295", 7.50mm Width)
Supplier Device Package	18-SOIC
