Name: FSA3051TMX
Brand: Fairchild Semiconductor
SKU: FSA3051TMX
Price: 0.56 USD
Availability: InStock

REF: FSA3051TMX Fairchild Semiconductor

FSA3051TMX

Fairchild Semiconductor

HIGH PERFORMANCE SPDT ANALOG SWI

FSA3051TMX is a Interface - Analog Switches, Multiplexers, Demultiplexers manufactured by Fairchild Semiconductor. HIGH PERFORMANCE SPDT ANALOG SWI. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 85°C (TA), package / case 6-XFDFN, number of circuits 1.

Datasheet Request a Quote

In Stock: 703,500

Tiered Pricing USD

1+ $0.5600 —

10+ $0.3950 -29%

25+ $0.3540 -37%

100+ $0.3083 -45%

250+ $0.2865 -49%

500+ $0.2734 -51%

1,000+ $0.2626 -53%

2,500+ $0.2511 -55%

5,000+ $0.2443 -56% BEST

Specifications

18 parameters

Product Status	Active
Switch Circuit	SPDT
Multiplexer/Demultiplexer Circuit	2:1
Number of Circuits	1
On-State Resistance (Max)	10Ohm
Channel-to-Channel Matching (ΔRon)	350mOhm
Voltage - Supply, Single (V+)	1.6V ~ 5.5V
Voltage - Supply, Dual (V±)	-
Switch Time (Ton, Toff) (Max)	34ns, 23ns (Typ)

-3db Bandwidth	1GHz
Charge Injection	-
Channel Capacitance (CS(off), CD(off))	3.3pF
Current - Leakage (IS(off)) (Max)	2µA
Crosstalk	-23dB @ 240MHz
Operating Temperature	-40°C ~ 85°C (TA)
Mounting Type	Surface Mount
Package / Case	6-XFDFN
Supplier Device Package	6-TMLP (1X1)
