Name: DI015N25D1
Brand: Diotec Semiconductor
SKU: DI015N25D1
Price: 1.37 USD
Availability: InStock

REF: DI015N25D1 Diotec Semiconductor

DI015N25D1

MOSFET N-CH 250V 15A TO252-3

DI015N25D1 is a Transistors - FETs, MOSFETs - Single manufactured by Diotec Semiconductor. MOSFET N-CH 250V 15A TO252-3. Key specifications: mounting type Surface Mount, operating temperature -55°C ~ 175°C (TJ), package / case TO-252-3, DPak (2 Leads + Tab), SC-63.

Datasheet Request a Quote

In Stock: 2,500

Specifications

17 parameters

Product Status	Active
FET Type	N-Channel
Technology	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)	250 V
Current - Continuous Drain (Id) @ 25°C	15A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	10V
Rds On (Max) @ Id, Vgs	255mOhm @ 15A, 10V
Vgs(th) (Max) @ Id	4.5V @ 250µA
Gate Charge (Qg) (Max) @ Vgs	8.9 nC @ 10 V

Vgs (Max)	±20V
Input Capacitance (Ciss) (Max) @ Vds	475 pF @ 125 V
FET Feature	-
Power Dissipation (Max)	140W (Tc)
Operating Temperature	-55°C ~ 175°C (TJ)
Mounting Type	Surface Mount
Supplier Device Package	TO-252-3, DPak
Package / Case	TO-252-3, DPak (2 Leads + Tab), SC-63
