MB2505

In Stock: 4,243
MB2505 - Diodes Incorporated - Diodes - Bridge Rectifiers
REF: MB2505 Diodes Incorporated
MB2505

Diodes Incorporated

BRIDGE RECT 1PHASE 50V 25A MB

MB2505 is a Diodes - Bridge Rectifiers manufactured by Diodes Incorporated. BRIDGE RECT 1PHASE 50V 25A MB. Key specifications: mounting type QC Terminal, operating temperature -55°C ~ 150°C (TJ), package / case 4-Square, MB.

Datasheet Request a Quote

In Stock: 4,243

Specifications

11 parameters
Product StatusObsolete
Diode TypeSingle Phase
TechnologyStandard
Voltage - Peak Reverse (Max)50 V
Current - Average Rectified (Io)25 A
Voltage - Forward (Vf) (Max) @ If1.1 V @ 12.5 A
Current - Reverse Leakage @ Vr10 µA @ 50 V
Operating Temperature-55°C ~ 150°C (TJ)
Mounting TypeQC Terminal
Package / Case4-Square, MB
Supplier Device PackageMB
