MB1505

In Stock: 3,099
MB1505 - Diodes Incorporated - Diodes - Bridge Rectifiers
REF: MB1505 Diodes Incorporated
MB1505

Diodes Incorporated

BRIDGE RECT 1PHASE 50V 15A MB

MB1505 is a Diodes - Bridge Rectifiers manufactured by Diodes Incorporated. BRIDGE RECT 1PHASE 50V 15A MB. Key specifications: mounting type QC Terminal, operating temperature -55°C ~ 150°C (TJ), package / case 4-Square, MB.

Datasheet Request a Quote

In Stock: 3,099

Specifications

11 parameters
Product StatusObsolete
Diode TypeSingle Phase
TechnologySchottky
Voltage - Peak Reverse (Max)50 V
Current - Average Rectified (Io)15 A
Voltage - Forward (Vf) (Max) @ If1.1 V @ 7.5 A
Current - Reverse Leakage @ Vr10 µA @ 50 V
Operating Temperature-55°C ~ 150°C (TJ)
Mounting TypeQC Terminal
Package / Case4-Square, MB
Supplier Device PackageMB
