Name: AS1751V-T
Brand: ams
SKU: AS1751V-T
Availability: InStock

REF: AS1751V-T ams

AS1751V-T

IC SWITCH QUAD SPST 16TQFN

AS1751V-T is a Interface - Analog Switches, Multiplexers, Demultiplexers manufactured by ams. IC SWITCH QUAD SPST 16TQFN. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 85°C (TA), package / case 16-WFQFN Exposed Pad, number of circuits 4.

Datasheet Request a Quote

In Stock: 3,352

Specifications

18 parameters

Product Status	Obsolete
Switch Circuit	SPST - NO
Multiplexer/Demultiplexer Circuit	1:1
Number of Circuits	4
On-State Resistance (Max)	900mOhm
Channel-to-Channel Matching (ΔRon)	30mOhm
Voltage - Supply, Single (V+)	1.6V ~ 3.6V
Voltage - Supply, Dual (V±)	-
Switch Time (Ton, Toff) (Max)	22ns, 14ns

-3db Bandwidth	-
Charge Injection	2pC
Channel Capacitance (CS(off), CD(off))	45pF, 45pF
Current - Leakage (IS(off)) (Max)	2.5nA
Crosstalk	-80dB @ 1MHz
Operating Temperature	-40°C ~ 85°C (TA)
Mounting Type	Surface Mount
Package / Case	16-WFQFN Exposed Pad
Supplier Device Package	16-TQFN (3x3)
