TYN20-800T,127

In Stock: 8,951
TYN20-800T,127 - WeEn Semiconductors - Thyristors - SCRs
REF: TYN20-800T,127 WeEn Semiconductors
TYN20-800T,127

WeEn Semiconductors

SCR 800V 20A TO220AB

TYN20-800T,127 is a Thyristors - SCRs manufactured by WeEn Semiconductors. SCR 800V 20A TO220AB. Key specifications: mounting type Through Hole, package / case TO-220-3.

Datasheet Request a Quote

In Stock: 8,951

Tiered Pricing USD
1+ $1.7200 —
50+ $0.8192 -52%
100+ $0.7313 -57%
500+ $0.5769 -66%
1,000+ $0.5272 -69%
2,000+ $0.4854 -72% BEST

Specifications

15 parameters
Product StatusActive
Voltage - Off State800 V
Voltage - Gate Trigger (Vgt) (Max)1.3 V
Current - Gate Trigger (Igt) (Max)32 mA
Voltage - On State (Vtm) (Max)1.5 V
Current - On State (It (AV)) (Max)12.7 A
Current - On State (It (RMS)) (Max)20 A
Current - Hold (Ih) (Max)40 mA
Current - Off State (Max)1 mA
Current - Non Rep. Surge 50, 60Hz (Itsm)210A, 231A
SCR TypeStandard Recovery
Operating Temperature-
Mounting TypeThrough Hole
Package / CaseTO-220-3
Supplier Device PackageTO-220AB
