Name: SISF20DN-T1-GE3
Brand: Vishay Siliconix
SKU: SISF20DN-T1-GE3
Price: 1.67 USD
Availability: InStock

REF: SISF20DN-T1-GE3 Vishay Siliconix

SISF20DN-T1-GE3

Vishay Siliconix

MOSFET DL N-CH 60V PPK 1212-8SCD

SISF20DN-T1-GE3 is a Transistors - FETs, MOSFETs - Arrays manufactured by Vishay Siliconix. MOSFET DL N-CH 60V PPK 1212-8SCD. Key specifications: mounting type Surface Mount, operating temperature -55°C ~ 150°C (TJ), package / case PowerPAK® 1212-8SCD, power - max 5.2W (Ta), 69.4W (Tc).

Datasheet Request a Quote

In Stock: 3,464

Specifications

14 parameters

Product Status	Active
FET Type	2 N-Channel (Dual)
FET Feature	Standard
Drain to Source Voltage (Vdss)	60V
Current - Continuous Drain (Id) @ 25°C	14A (Ta), 52A (Tc)
Rds On (Max) @ Id, Vgs	13mOhm @ 7A, 10V
Vgs(th) (Max) @ Id	3V @ 250µA

Gate Charge (Qg) (Max) @ Vgs	33nC @ 10V
Input Capacitance (Ciss) (Max) @ Vds	1290pF @ 30V
Power - Max	5.2W (Ta), 69.4W (Tc)
Operating Temperature	-55°C ~ 150°C (TJ)
Mounting Type	Surface Mount
Package / Case	PowerPAK® 1212-8SCD
Supplier Device Package	PowerPAK® 1212-8SCD
