VS-RA160FA120

In Stock: 146
VS-RA160FA120 - Vishay General Semiconductor - Diodes Division - Diodes - Rectifiers - Arrays
REF: VS-RA160FA120 Vishay General Semiconductor - Diodes Division
VS-RA160FA120

Vishay General Semiconductor - Diodes Division

DIODE MODULE 1200V 91A SOT227

VS-RA160FA120 is a Diodes - Rectifiers - Arrays manufactured by Vishay General Semiconductor - Diodes Division. DIODE MODULE 1200V 91A SOT227. Key specifications: mounting type Chassis Mount, package / case SOT-227-4, miniBLOC.

Datasheet Request a Quote

In Stock: 146

Specifications

13 parameters
Product StatusActive
Diode Configuration2 Independent
Diode TypeStandard
Voltage - DC Reverse (Vr) (Max)1200 V
Current - Average Rectified (Io) (per Diode)91A
Voltage - Forward (Vf) (Max) @ If1.27 V @ 100 A
SpeedStandard Recovery >500ns, > 200mA (Io)
Reverse Recovery Time (trr)-
Current - Reverse Leakage @ Vr150 µA @ 1200 V
Operating Temperature - Junction-55°C ~ 150°C
Mounting TypeChassis Mount
Package / CaseSOT-227-4, miniBLOC
Supplier Device PackageSOT-227
