Name: VBUS05M2-HT5-G3-08
Brand: Vishay General Semiconductor - Diodes Division
SKU: VBUS05M2-HT5-G3-08
Price: 0.37 USD
Availability: InStock

REF: VBUS05M2-HT5-G3-08 Vishay General Semiconductor - Diodes Division

VBUS05M2-HT5-G3-08

Vishay General Semiconductor - Diodes Division

TVS DIODE 5.5VWM 27VC DFN1110-3A

VBUS05M2-HT5-G3-08 is a TVS - Diodes manufactured by Vishay General Semiconductor - Diodes Division. TVS DIODE 5.5VWM 27VC DFN1110-3A. Key specifications: mounting type Surface Mount, Wettable Flank, operating temperature -55°C ~ 150°C (TJ), package / case 3-XDFN Exposed Pad.

Datasheet Request a Quote

In Stock: 9,634

Tiered Pricing USD

1+ $0.3700 —

10+ $0.2280 -38%

100+ $0.1430 -61%

500+ $0.1062 -71%

1,000+ $0.0887 -76%

2,000+ $0.0843 -77%

5,000+ $0.0734 -80% BEST

Specifications

16 parameters

Product Status	Active
Type	Zener
Unidirectional Channels	-
Bidirectional Channels	2
Voltage - Reverse Standoff (Typ)	5.5V (Max)
Voltage - Breakdown (Min)	7.5V
Voltage - Clamping (Max) @ Ipp	27V (Typ)
Current - Peak Pulse (10/1000µs)	3.4A (8/20µs)

Power - Peak Pulse	60W
Power Line Protection	No
Applications	Automotive
Capacitance @ Frequency	0.37pF @ 1MHz
Operating Temperature	-55°C ~ 150°C (TJ)
Mounting Type	Surface Mount, Wettable Flank
Package / Case	3-XDFN Exposed Pad
Supplier Device Package	DFN1110-3A
