81CNQ045ASM

In Stock: 5,394
81CNQ045ASM - Vishay General Semiconductor - Diodes Division - Diodes - Rectifiers - Arrays
REF: 81CNQ045ASM Vishay General Semiconductor - Diodes Division
81CNQ045ASM

Vishay General Semiconductor - Diodes Division

DIODE ARRAY SCHOTTKY 45V D618SM

81CNQ045ASM is a Diodes - Rectifiers - Arrays manufactured by Vishay General Semiconductor - Diodes Division. DIODE ARRAY SCHOTTKY 45V D618SM. Key specifications: mounting type Through Hole, package / case D-61-8-SM.

Datasheet Request a Quote

In Stock: 5,394

Specifications

13 parameters
Product StatusObsolete
Diode Configuration1 Pair Common Cathode
Diode TypeSchottky
Voltage - DC Reverse (Vr) (Max)45 V
Current - Average Rectified (Io) (per Diode)40A
Voltage - Forward (Vf) (Max) @ If740 mV @ 80 A
SpeedFast Recovery =< 500ns, > 200mA (Io)
Reverse Recovery Time (trr)-
Current - Reverse Leakage @ Vr5 mA @ 45 V
Operating Temperature - Junction-55°C ~ 175°C
Mounting TypeThrough Hole
Package / CaseD-61-8-SM
Supplier Device PackageD-61-8-SM
