UC2823N

In Stock: 19,367
UC2823N - Unitrode - PMIC - Voltage Regulators - DC DC Switching Controllers
REF: UC2823N Unitrode
UC2823N

Unitrode

UC2823 HIGH SPEED PWM CONTROLLER

UC2823N is a PMIC - Voltage Regulators - DC DC Switching Controllers manufactured by Unitrode. UC2823 HIGH SPEED PWM CONTROLLER. Key specifications: mounting type Through Hole, operating temperature -25°C ~ 85°C (TA), voltage - supply (vcc/vdd) 8.4V ~ 30V, package / case 16-DIP (0.300", 7.62mm).

Datasheet Request a Quote

In Stock: 19,367

Specifications

18 parameters
Product StatusActive
Output TypeTransistor Driver
FunctionStep-Up, Step-Down, Step-Up/Step-Down
Output ConfigurationPositive
TopologyBuck, Boost, Flyback, Forward Converter
Number of Outputs1
Output Phases1
Voltage - Supply (Vcc/Vdd)8.4V ~ 30V
Frequency - Switching340kHz ~ 460kHz
Duty Cycle (Max)80%
Synchronous RectifierNo
Clock SyncNo
Serial Interfaces-
Control FeaturesCurrent Limit, Enable, Frequency Control, Ramp, Soft Start
Operating Temperature-25°C ~ 85°C (TA)
Mounting TypeThrough Hole
Package / Case16-DIP (0.300", 7.62mm)
Supplier Device Package16-PDIP
