Name: UJ3N120065K3S
Brand: UnitedSiC
SKU: UJ3N120065K3S
Price: 21.10 USD
Availability: InStock

REF: UJ3N120065K3S UnitedSiC

UJ3N120065K3S

1200V/65MOHM, SIC, N-ON JFET, G3

UJ3N120065K3S is a Transistors - JFETs manufactured by UnitedSiC. 1200V/65MOHM, SIC, N-ON JFET, G3. Key specifications: mounting type Through Hole, operating temperature -55°C ~ 175°C (TJ), package / case TO-247-3, power - max 254 W.

Datasheet Request a Quote

In Stock: 7,703

Tiered Pricing USD

1+ $21.1000 —

30+ $13.3227 -37%

120+ $12.1000 -43% BEST

Specifications

14 parameters

Product Status	Active
FET Type	N-Channel
Voltage - Breakdown (V(BR)GSS)	1.2 V
Drain to Source Voltage (Vdss)	1.2 V
Current - Drain (Idss) @ Vds (Vgs=0)	5 µA @ 1.2 V
Current Drain (Id) - Max	34 A
Voltage - Cutoff (VGS off) @ Id	-

Input Capacitance (Ciss) (Max) @ Vds	1008pF @ 100V
Resistance - RDS(On)	55 mOhms
Power - Max	254 W
Operating Temperature	-55°C ~ 175°C (TJ)
Mounting Type	Through Hole
Package / Case	TO-247-3
Supplier Device Package	TO-247-3
