Name: 4N22U
Brand: TT Electronics/Optek Technology
SKU: 4N22U
Availability: InStock

REF: 4N22U TT Electronics/Optek Technology

4N22U

OPTOISO 1KV TRANS W/BASE 6LCC

4N22U is a Optoisolators - Transistor, Photovoltaic Output manufactured by TT Electronics/Optek Technology. OPTOISO 1KV TRANS W/BASE 6LCC. Key specifications: mounting type Surface Mount, operating temperature -55°C ~ 125°C, voltage - forward (vf) (typ) 1.3V (Max), package / case 6-SMD, No Lead.

Datasheet Request a Quote

In Stock: 2,328

Specifications

18 parameters

Product Status	Obsolete
Number of Channels	1
Voltage - Isolation	1000VDC
Current Transfer Ratio (Min)	25% @ 10mA
Current Transfer Ratio (Max)	-
Turn On / Turn Off Time (Typ)	-
Rise / Fall Time (Typ)	15µs, 15µs
Input Type	DC
Output Type	Transistor with Base

Voltage - Output (Max)	35V
Current - Output / Channel	-
Voltage - Forward (Vf) (Typ)	1.3V (Max)
Current - DC Forward (If) (Max)	40 mA
Vce Saturation (Max)	300mV
Operating Temperature	-55°C ~ 125°C
Mounting Type	Surface Mount
Package / Case	6-SMD, No Lead
Supplier Device Package	6-LCC (6.22x4.32)
