TLP3073(LF1,F

In Stock: 6,416
TLP3073(LF1,F - Toshiba Semiconductor and Storage - Optoisolators - Triac, SCR Output
REF: TLP3073(LF1,F Toshiba Semiconductor and Storage
TLP3073(LF1,F

Toshiba Semiconductor and Storage

OPTO TRIAC COUPLER; NON-ZERO-VOL

TLP3073(LF1,F is a Optoisolators - Triac, SCR Output manufactured by Toshiba Semiconductor and Storage. OPTO TRIAC COUPLER; NON-ZERO-VOL. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 100°C, voltage - forward (vf) (typ) 1.15V, package / case 6-SMD (5 Leads), Gull Wing.

Datasheet Request a Quote

In Stock: 6,416

Tiered Pricing USD
1+ $1.8100 —
50+ $1.0582 -42%
100+ $0.9811 -46%
500+ $0.8436 -53%
1,000+ $0.7987 -56%
2,000+ $0.7607 -58%
5,000+ $0.7193 -60%
10,000+ $0.6935 -62% BEST

Specifications

18 parameters
Product StatusActive
Output TypeTriac
Zero Crossing CircuitNo
Number of Channels1
Voltage - Isolation5000Vrms
Voltage - Off State800 V
Static dV/dt (Min)2000V/µs (Typ)
Current - LED Trigger (Ift) (Max)5mA
Current - On State (It (RMS)) (Max)100 mA
Current - Hold (Ih)1mA (Typ)
Turn On Time-
Voltage - Forward (Vf) (Typ)1.15V
Current - DC Forward (If) (Max)50 mA
Operating Temperature-40°C ~ 100°C
Mounting TypeSurface Mount
Package / Case6-SMD (5 Leads), Gull Wing
Supplier Device Package6-SO, 5 Lead
Approval AgencyCQC, cUR, UR
