UCC5870QDWJQ1

In Stock: 7,779
UCC5870QDWJQ1 - Texas Instruments - Isolators - Gate Drivers
REF: UCC5870QDWJQ1 Texas Instruments
UCC5870QDWJQ1

Texas Instruments

IC ISOLATION

UCC5870QDWJQ1 is a Isolators - Gate Drivers manufactured by Texas Instruments. IC ISOLATION. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 125°C, package / case 36-BSSOP (0.295", 7.50mm Width).

Request a Quote

In Stock: 7,779

Specifications

18 parameters
Product StatusActive
TechnologyCapacitive Coupling
Number of Channels1
Voltage - Isolation3750Vrms
Common Mode Transient Immunity (Min)100kV/µs
Propagation Delay tpLH / tpHL (Max)150ns, 150ns
Pulse Width Distortion (Max)-
Rise / Fall Time (Typ)150ns, 150ns (Max)
Current - Output High, Low30A, 30A
Current - Peak Output30A
Voltage - Forward (Vf) (Typ)-
Current - DC Forward (If) (Max)-
Voltage - Output Supply15V ~ 30V
Operating Temperature-40°C ~ 125°C
Mounting TypeSurface Mount
Package / Case36-BSSOP (0.295", 7.50mm Width)
Supplier Device Package36-SSOP
Approval Agency-
