UCC5390ECDWVR

In Stock: 2,249
UCC5390ECDWVR - Texas Instruments - Isolators - Gate Drivers
REF: UCC5390ECDWVR Texas Instruments
UCC5390ECDWVR

Texas Instruments

DGTL ISO 3KV 1CH GATE DRVR 8SOIC

UCC5390ECDWVR is a Isolators - Gate Drivers manufactured by Texas Instruments. DGTL ISO 3KV 1CH GATE DRVR 8SOIC. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 125°C, package / case 8-SOIC (0.295", 7.50mm Width), approval agency CQC, CSA, UR, VDE.

Datasheet Request a Quote

In Stock: 2,249

Tiered Pricing USD
1+ $2.7900 —
10+ $2.0830 -25%
25+ $1.9064 -32%
100+ $1.7117 -39%
250+ $1.6189 -42%
500+ $1.5629 -44% BEST

Specifications

18 parameters
Product StatusActive
TechnologyCapacitive Coupling
Number of Channels1
Voltage - Isolation3000Vrms
Common Mode Transient Immunity (Min)100kV/µs
Propagation Delay tpLH / tpHL (Max)100ns, 100ns
Pulse Width Distortion (Max)20ns
Rise / Fall Time (Typ)10ns, 10ns
Current - Output High, Low10A, 10A
Current - Peak Output-
Voltage - Forward (Vf) (Typ)-
Current - DC Forward (If) (Max)-
Voltage - Output Supply13.2V ~ 33V
Operating Temperature-40°C ~ 125°C
Mounting TypeSurface Mount
Package / Case8-SOIC (0.295", 7.50mm Width)
Supplier Device Package8-SOIC
Approval AgencyCQC, CSA, UR, VDE
