UCC5320SCDWVR

In Stock: 7,138
UCC5320SCDWVR - Texas Instruments - Isolators - Gate Drivers
REF: UCC5320SCDWVR Texas Instruments
UCC5320SCDWVR

Texas Instruments

2A /2A 5KVRMS ISOGATE DR-SPLIT O

UCC5320SCDWVR is a Isolators - Gate Drivers manufactured by Texas Instruments. 2A /2A 5KVRMS ISOGATE DR-SPLIT O. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 125°C, package / case 8-SOIC (0.295", 7.50mm Width), approval agency CQC, UR, VDE.

Datasheet Request a Quote

In Stock: 7,138

Tiered Pricing USD
1+ $2.2100 —
10+ $1.6360 -26%
25+ $1.4924 -32%
100+ $1.3345 -40%
250+ $1.2592 -43%
500+ $1.2138 -45% BEST

Specifications

18 parameters
Product StatusActive
TechnologyCapacitive Coupling
Number of Channels1
Voltage - Isolation3000Vrms
Common Mode Transient Immunity (Min)100kV/µs
Propagation Delay tpLH / tpHL (Max)75ns, 75ns
Pulse Width Distortion (Max)20ns
Rise / Fall Time (Typ)12ns, 10ns
Current - Output High, Low2.4A, 2.2A
Current - Peak Output4.3A
Voltage - Forward (Vf) (Typ)-
Current - DC Forward (If) (Max)-
Voltage - Output Supply13.2V ~ 33V
Operating Temperature-40°C ~ 125°C
Mounting TypeSurface Mount
Package / Case8-SOIC (0.295", 7.50mm Width)
Supplier Device Package8-SOIC
Approval AgencyCQC, UR, VDE
